Entities | |
| Behavioral | architecture |
Libraries | |
| UNISIM | |
Use Clauses | |
| amc13_pack | Package <amc13_pack> |
| VComponents | |
| mydefs | Package <mydefs> |
Generics | |
| N_SFP | integer := 1 |
Ports | |
| sys_reset | in STD_LOGIC |
| sys_clk | in STD_LOGIC |
| sfp_pd | in array2x2 |
| DRP_clk | in STD_LOGIC |
| LinkWe | in STD_LOGIC_VECTOR ( 1 downto 0 ) |
| LinkCtrl | in STD_LOGIC_VECTOR ( 1 downto 0 ) |
| LinkData | in array2x64 |
| srcID | in array2x16 |
| LinkDown | out STD_LOGIC_VECTOR ( 1 downto 0 ) |
| LinkFull | out STD_LOGIC_VECTOR ( 1 downto 0 ) |
| sync_loss | out STD_LOGIC_VECTOR ( 1 downto 0 ) |
| status_ce | in std_logic_VECTOR ( 1 downto 0 ) |
| status_addr | in STD_LOGIC_VECTOR ( 15 downto 0 ) |
| status_port | out array2x64 |
| txusrclk_o | out STD_LOGIC |
| rxusrclk_o | out STD_LOGIC |
| gtx_reset | in std_logic |
| gtx_refclk | in std_logic |
| sfp_rxn | in std_logic_VECTOR ( 1 downto 0 ) |
| sfp_rxp | in std_logic_VECTOR ( 1 downto 0 ) |
| sfp_txn | out std_logic_VECTOR ( 1 downto 0 ) |
| sfp_txp | out std_logic_VECTOR ( 1 downto 0 ) |
| gtx_refclk_p | in std_logic |
| gtx_refclk_n | in std_logic |
Definition at line 11 of file DaqLSCXG.vhd.
